Advance HCL320F Hydraulic Clutch

Advance HCL320F hydraulic clutch has a speed input range of 1000-2500 r/min, a transmission torque of 3.2 kN/m, an input power of 335 kW to 838 kW, a transmission capacity range of 0.335 kW/RPM and a net weight of 210 kg.

Advanced HCL320F hydraulic clutch can be matched with different steering diesel engines, and is suitable for long-term engagement of continuous working machinery or frequent clutching of non-continuous working machinery, as well as no-load starting of working machinery, and can be widely matched with all kinds of marine auxiliary engines or general-purpose machinery. HCL320F hydraulic clutch has the function of clutching, and the product has the characteristics of small size, light weight, high transmission torque and long life. In order to meet the different requirements of coupling with different brands and models of engines, it can be customized according to customer needs.

All of our Advance HCL series hydraulic clutch can provide CCS classification certificate, some of series can provide international classifications with extra costs which mainly including French BV, British LR, American ABS, Japanese NK , Norway DNV-GL, Russia RS, South Korea KR, Italy RINA and other classification societies.

Coming soon

1. This series of hydraulic clutch can be matched with different steering diesel engines.
2. This hydraulic clutch is wet multi-disc powder metallurgy friction plate structure, which is suitable for long-term engagement of continuous working machinery or frequent clutching of non-continuous working machinery, and also suitable for no-load starting of working machinery.
3. It can be widely used in various ship auxiliary machines or general machinery (such as generators, fans, various pumps, net machines, etc.).
4. The product has two operation modes of mechanical control and electrical control, which is flexible in operation and easy to realize long-distance control.
5. The product has the characteristics of small volume, light weight, high transmission torque and long life.
6. the product has a high level of product “three”, high degree of generalization of maintenance spare parts, easy to purchase.

Technical Specifications

Basic Introduction of  Advance HCL320F Hydraulic Clutches

Genset Model:HCL320F
Input Speed:1000-2500 RPM
Power:335-838 kW
Center Distance:N/A
Trans.Capacity:0.335 kW/RPM
Trans.Torque:3.2 kN·m
Rated Thrust:N/A
Dimension:554 mm * 425 mm * 635 mm
Net Weight:210 kg
Lead Time:15-30 Working Days
Payment Terms:T/T ,L/C
The picture of Performance Curve-DCEC Cummins Industrial Engine

Model

Input Speed

Transmit Torque

Trans. Capacity

Dimension

Net Weight

HCL30S750~1500 r/min0.3 kN·m0.031 kW/r/min345 mm * 310 mm * 455 mm100 kg
HCL30F1500-2500 r/min0.3 kN·m0.031 kW/r/min345 mm * 310 mm * 455 mm100 kg
HCL100S750-1500 r/min1 kN·m0.105 kW/r/min570 mm * 420 mm * 535 mm156 kg
HCL100F1500-2500 r/min1 kN·m0.105 kW/r/min570 mm * 420 mm * 535 mm156 kg
HCL250S750-1000 r/min2.5 kN·m0.262 kW/r/min554 mm * 425 mm * 635 mm210 kg
HCL250F1000-2500 r/min2.5 kN·m0.262 kW/r/min554 mm * 425 mm * 635 mm210 kg
HCL320S500-1000 r/min3.2 kN·m0.335 kW/r/min554 mm * 425 mm * 635 mm210 kg
HCL320F1000-2500 r/min3.2 kN·m0.335 kW/r/min554 mm * 425 mm * 635 mm210 kg
HCL450S500-1000 r/min4.5 kN·m0.471 kW/r/min554 mm * 425 mm * 635 mm230 kg
HCL450F1000-2500 r/min4.5 kN·m0.471 kW/r/min554 mm * 425 mm * 635 mm230 kg
HCL600S750-1000 r/min6 kN·m0.628 kW/r/min746 mm * 560 mm * 688 mm450 kg
HCL600F1000-1600 r/min6 kN·m0.628 kW/r/min746 mm * 560 mm * 688 mm450 kg
HCL800S750-1000 r/min8 kN·m0.837 kW/r/min746 mm * 560 mm * 688 mm450 kg
HCL800F1000-1800 r/min8 kN·m0.837 kW/r/min746 mm * 560 mm * 688 mm450 kg
HCL1000S750-1000 r/min10 kN·m1.047 kW/r/min915 mm * 800 mm * 1005 mm800 kg
HCL1000F1000-1800 r/min10 kN·m1.047 kW/r/min915 mm * 800 mm * 1005 mm800 kg
——END——

No related content yet, stay tuned!

1. The Marine gearbox has the function of reverse, clutch, deceleration and the thrust of the propeller, which is equipped with the main engine to form the Marine power unit.
2. The “transfer capacity” refers to the ratio of the engine’s rated power to the rated speed, and the reduction ratio corresponds to the transmission capacity, which should be less than the number be offered.
3. The gearbox and engine shafting are not allowed to use rigid connection, and the bracket is recommended to be installed on the same rigid support.If the engine is mounted on the elastic support, and the gearbox is installed on the rigid support, please contact the technical department of the company to select the suitable high elastic coupling.
4. The weight of the gearbox is approximation, for different reduction ratio the weight is different.
5. Due to the technical improvement of the products, the products may change without notice. For any other questions please contact our sales engineer.

ANGLE OF TILT

NameTransverse DirectionLongitudinal Direction
HeelingRollingHeelingRolling
Marine Gearbox15°22.5°7.5°
——END——



No related content yet, stay tuned!

Marine Gearboxs Conventional Wearing Parts

External discInternal discSealingPiston ring
GasketRubber sealingThrust plateFilter
Coil type filterPackingO ringInput shaft assembly
Transmission shaft assembyOutput shaft assemblyHydraulic control system
——END——




DCECDCEC
CCECCCEC
DeutzDeutz
WeichaiWeichai
Medium-Low DutyBCP | TBP
Medium-Heavy DutyLPSP/HPSP | CSP
Light Duty & High SpeedCFP | WSP
 Gw SeriesFBP| DSP
DCECCDQY
CCECCDDY
DeutzCJRZ
WeichaiCDRZ



Note: All Above Data are Just for Referenece, All Data Might Change Without Notices or Update, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.

The picture of Sale Manual showing the accessories and scopes of supply.

Engine Sale Manual

The picture of Installation Drawing showing the accessories and scopes of supply.

Installation Drawing

The picture of Installation Manual showing the accessories and scopes of supply.

Installation Manual

The picture of Operation Manual showing the accessories and scopes of supply.

Operation Manual

The picture of Engine Parts Catalogue showing the accessories and scopes of supply.

Parts Catalogue

The picture of Test Report and Certifcate showing the accessories and scopes of supply.

Report & Certifcate
