Advance DJQ01 Agricultural knotter

Advance DJQ01 agricultural knotter spindle speed is 100 rpm, and overall dimensions (length × width × height) are 306mm × 204mm × 148mm.
Advance DJQ01 agricultural knotter is mainly used in the baling operation of square balers and is the core component of picking up square balers. This type of knotter adopts the principle of bionics to simulate the knotting action of human fingers to achieve efficient knotting of straw bales and integrated control of the knotting process. It has a forced rope release structure, reliable knotting performance and high bale rate.
Each part of this type of knotter is made of special materials and processed with special processes, which makes it wear-resistant, reliable and has a long service life.
All of our Advance Bale Straw Series Agricultural gearbox can provide CCS classification certificate, some of series can provide international classifications with extra costs which mainly including French BV, British LR, American ABS, Japanese NK , Norway DNV-GL, Russia RS, South Korea KR, Italy RINA and other classification societies.

Advantages of Advance DJQ01 Agricultural Gearbox

Gearbox novel structure, so that its use becomes very reliable. The excellent design makes the gearbox and engine arrangement more soft and smooth.
It can be matched with high-speed diesel engines at home and abroad, and can be arranged in vertical, horizontal and inclination according to the needs of users.
Compact structure, small size, light weight and good operability. The convenience of use and maintenance is fully considered in the design.
The gearbox have adapted to combined design, and all running parts have been carefully designed and machined to the highest standards for less wasted fuel, smooth operation which can be fitted to most engine models.
With excellent machine performance, good design effectively reduce the noise, reduce the vibration,better deceleration effect and bearing propeller thrust.
Professional gearbox specialists and after-sales service, spare parts directly available from stock.

Technical Specifications

Gearbox Model:LB	LB40
Maximum input speed:	2800 RPM
Power:	40 kW @ 2800 RPM
Trans.Capacity:	0.278-0.625 kW / RPM
Rated Input Torque:	75N•m
fully loaded:	2.8t
Lead Time:	15-30 Working Days
Payment Terms:	T/T ,L/C

Item	Parameters
Maximum input power	40kW
Rated input torque	75N•m
Maximum input speed	2800 r/min
Maximum cutting width	2m
Full load	2.8t
Supported HST displacement	28L
Input gear ratio Transmission ratio 26:14 18.566；25.196；35.586 25:15 16.622；22.612；31.936 24:16 14.996；20.352；28.743 23:17 13.526；18.357；25.925

Gearbox Model:	DJQ01
The spindle speed:	100 rpm
The overall dimensions (length × width × height):	306 mm×204 mm×148 mm

Coming soon

Engine Model	Rated Power	Engine Model	Rated Power
9YFQ-08 (single speed)	25.7 kW @ 540 RPM	9YFQ-08 (two speed)	90 kW @ 540/720 RPM
9YFS-08	35 kW @ 540 RPM	9YG-1.2	35 kW @ 540 RPM
JSQ-15	40 kW @ 540 RPM	9YFA-220	42 kW @ 250 RPM
9YFQ185.02B.01	48 kW @ 540 RPM	YKJ110F/I	80 kW @ 720 RPM
5JF190	191 kW @ 1000 RPM	5JF192	191.2 kW @ 1000 RPM
DJQ01	100 RPM	J3U8	550 RPM
——END——

1. The Marine gearbox has the function of reverse, clutch, deceleration and the thrust of the propeller, which is equipped with the main engine to form the Marine power unit. 2. The “transfer capacity” refers to the ratio of the engine’s rated power to the rated speed, and the reduction ratio corresponds to the transmission capacity, which should be less than the number be offered. 3. The gearbox and engine shafting are not allowed to use rigid connection, and the bracket is recommended to be installed on the same rigid support.If the engine is mounted on the elastic support, and the gearbox is installed on the rigid support, please contact the technical department of the company to select the suitable high elastic coupling. 4. The weight of the gearbox is approximation, for different reduction ratio the weight is different. 5. Due to the technical improvement of the products, the products may change without notice. For any other questions please contact our sales engineer.

ANGLE OF TILT
Name	Transverse Direction		Longitudinal Direction
	Heeling	Rolling	Heeling	Rolling
Marine Gearbox	15°	22.5°	5°	7.5°
——END——
